Sikafloor® Terrazzo

Sikafloor® Terrazzo

Low VOC, Low Odour, Pigmented Epoxy Resin Binder for Thin-Set Terrazzo Floor Systems 6 - 9 mm

Sikafloor® Terrazzo is a two- component, solid color, low VOC, low odour, selfpriming, thin-set epoxy resin binder available in an unlimited color selection. Vibrant epoxy matrix colors can be combined in varying percentages with fine and or coarse mineral aggregates (marble or granite), colored or recycled glass, mirror particles, plastic chips and non-corrosive metal fragments to produce limitless customer design options. Sikafloor® Terrazzo is an extremely durable seamless finish that has excellent resistance to abrasion and common chemicals.

  • Meets the Terrazzo, Tile and Marble Association of Canada (TTMAC) and the
  • National Terrazzo and Mosaic Association (NTMA) standards for epoxy terrazzo.
  • Unmatched design versatility with custom capabilities.
  • Seamless, waterproof and easy to clean and maintain.
  • Exceptional abrasion resistance and durability.
  • Unlimited colors, no minimum required.
  • Can be filled with recycled aggregates.
  • Very low life cycle costs compared to other floor finishes.
Product Data Sheet Show all documents

Usage

Sikafloor® Terrazzo is the ideal choice to provide extreme durability and easy of maintenance in heavy traffic commercial and institutional areas such as hospitals, pharmaceutical research centers, schools, banks, building lobbies, shopping centers, grocery stores, airport terminals, train stations, convention centers.

Advantages

  • Meets the Terrazzo, Tile and Marble Association of Canada (TTMAC) and the
  • National Terrazzo and Mosaic Association (NTMA) standards for epoxy terrazzo.
  • Unmatched design versatility with custom capabilities.
  • Seamless, waterproof and easy to clean and maintain.
  • Exceptional abrasion resistance and durability.
  • Unlimited colors, no minimum required.
  • Can be filled with recycled aggregates.
  • Very low life cycle costs compared to other floor finishes.

Packaging

Part A:

19.3kg containers

Part B:   4.7 kg containers
Part C:   1.0 kg containers

Part D:

25 kg bag

Colour

Resin - part A:

coloured, liquid

Hardener - part B:

transparent, liquid

pigment- part C:coloured, liquid
Aggregate- part D:coloured, powder

Other colours, please inquire Sika.

Product Details

Sustainability / Certifications / Approvals

ENVIRONMENTAL INFORMATION

Sikafloor® Terrazzo is listed on the Eco-Product Directory as environmentally friendly product choice for green building initiatives. (application no.: PL-01460-2022)

APPROVALS / STANDARDS

Meet to the requirements of GB/T 22374, GB/T 2567-2008
Product Information

Chemical Base

epoxy resin

Shelf Life

12 months from date of production

Storage Conditions

Stored properly in original, unopened and undamaged sealed packaging in dry conditions at temperatures between +5°C and +30°C.

Density

Part A:

~1.4 kg/l

Part B:

~1.0 kg/l

Part C:~1.5 kg/l

Mixed resin:

~1.4 kg/l

All Density values at +23°C.

Solid Content by Weight

100%

Solid Content by Volume

100%

Volatile Organic Compound (VOC) Content

<60g/L

GB/T 22374
Technical Information

Shore D Hardness

~85

GB/T 22374-2018

Abrasion Resistance

< 0.03 g

GB/T 22374-2018

Resistance to Impact

heavy

Compressive Strength

~ 63 MPa

GB/T 22374-2018

Tensile Adhesion Strength

≥ 3 MPa (failure in concrete)

GB/T 22374-2018

Thermal Compatibility

Exposure Dry heat Permanent

+50°C

Short-term max. 7 d

+80°C

Short-term max. 8 h *

+100°C


Short-term moist/wet heat* up to +80°C where exposure is only occasiona (steam cleaning etc.)
*No simultaneous chemical and mechanical exposure.

Chemical Resistance

Resistant to many chemicals. Please ask for a detailed chemical resistance table.

Application

Application Information

Mixing Ratio

Part A : Part B: Part C =77:19:4 (by weight)
(A+B+C) : Aggregate = 1:4
*Resin/Aggregate recommended ratio is 1:4.

Ambient Air Temperature

+10°C min. / +30°C max.

Relative Air Humidity

80% r.h. max.

Dew Point

Beware of condensation!
The substrate and uncured floor must be at least 3 °C above dew point to reduce the risk of condensation or blooming on the floor finish.

Substrate Temperature

+10°C min. / +30°C max.

Substrate Moisture Content

< 4% pbw moisture content.
Test method: Sika®-Tramex meter, CM - measurement or Oven-dry-method.
No rising moisture according to ASTM (Polyethylene-sheet).
Consumption

Consumption

System

Product

Consumption

Levelling(optional):

Sikafloor®-Level

~1.7kg/mm/m2

Primer:

1-2 x Sikafloor®-156/-161L

0.3-0.5kg/m2

Anti-cracking layer:Sikafloor®-325SL1-1.4kg/m2
Terrazzo mortar:Sikafloor® Terrazzo + Aggregate~2.5kg/mm/m2
Sealer:Sikafloor®-169 CN~0.2kg/m2
Curing agent(optional):Sikafloor®-Proseal Finish0.1-0.2kg/m2

These figures are theoretical and do not allow for any additional material due to surface porosity, surface profile, variations in level and wastage
etc. Lower consumption can cause gloss differences and irregular surface structure,The actual addition of aggregate should be depending on temperature and thickness on site.


Application steps

MIXING

Precondition material for at least 24 hours to between 18° to 26°C before use to assist application and achieve the best results.
Pre-stir thoroughly each component of Sikafloor® Terrazzo to ensure all solids and pigments are evenly distributed and even colour or clarity and consistency are achieved within each component.
Where supply format permits, empty Component B into Component A. Alternatively and in the correct ratio by quantity Component A: Component B, empty material into a suitably sized and clean mixing vessel and thoroughly mix using a low-speed drill (300 - 450 rpm) and Exomixer-type mixing-paddle (recommended model). To minimize entrapping air, ensure mixing paddle is kept in the material. To the 25kg mixed unit, slowly add marble dust filler and selected aggregate chips. During the mixing operation, scrape down the sides and bottom of the pail with a flat or straight-edge trowel at least once to ensure thorough mixing. When completely mixed. Sikafloor® Terrazzo should be uniform in colour, aggregate chips should be thoroughly wetted out and the consistency should be homogeneous before use.
Mix only the quantity you can use within its pot life.

APPLICATION

Sikafloor® Terrazzo epoxy matrix can be combined with a wide range of fine and coarse mineral aggregate chips (marble or granite), coloured or recycled glass, mirror particles, plastic and non-corrosive metal fragments. these aggregates can all significantly affect the application properties, coverage rate achieved and final appearance.The applicator’s preferred installation technique (slurry and broadcast or traditional screed and trowel) methodology will determine an individual contractor’s preference for thixotropy. The addition rate of marble dust is variable as it absorbs resin, thickening the matrix, allowing the applicator to make adjustments to meet their specific application technique or site environmental conditions. Due to the wide variety of aggregate chips used to create an unlimited design pallet, it is impractical to produce a single specific mix design that will meet the needs of all parties involved.

The Sikafloor® Terrazzo mix design provided below is a starting point that requires further refinement. It is the responsibility of the terrazzo applicator to conduct additional project specific mix design mock-ups, to finalize adjustments to the mix to achieve an acceptable final appearance, establish production rates, predict pinhole frequency and finalize aggregate and epoxy consumption.

Alternative aggregate chips types, i.e. glass, plastic and non-corrosive metal can be incorporated into the mix design, consult Sika China Technical Services Department for advice.

Pour mixture of Sikafloor® Terrazzo onto the floor, immediately spread and compact the mortar to the desired thickness using a 75 mm (3 in) wide steel trowel. Take care to spread newly mixed materials across the transition of previous applied mixes before the surface begins to set. Allow the applied terrazzo to cure for 18 hours at 23°C before initiating the grinding operation.

CLEANING OF TOOLS

Clean all tools and application equipment with Thinner C immediately after use.

Hardened and/or cured material can only be removed mechanically.
